Voltage Divider Online Calculator

Hey guys, welcome back to my blog. Here you will get a voltage divider online calculator to calculate the output voltage, and we will also discuss what is voltage divider, the formula for voltage divider, applications, etc.

If you have any electrical, electronics, and computer science doubts, then ask questions. You can also catch me on Instagram – CS Electrical & Electronics

Voltage Divider Online Calculator

Voltage divider formula,

A voltage divider is a viral circuit in the electronics field. The goal of the voltage divider is to convert the higher voltage level into the lower voltage and the voltage divider circuit uses a pair of resistors i.e., R1 & R2. The circuit of the voltage divider is shown below.

circuit of voltage divider — circuit of the voltage divider

In the above circuit,

Vs is known as the source voltage and is measured in volts
R1 is the resistance of the first resistor and is measured in ohms
R2 is the resistance of the second resistor and is measured in ohms
V_out / V is the output voltage and is measured in volts

Working of the voltage divider

The voltage divider is mainly used for reducing the source voltage. Two resistors are connected in series to drop some amount of voltage. By using just two resistors we can reduce the voltage and the complexity of designing it is very minor. As you can see from the above formula, the voltage divider takes three inputs such as Vs, R1, and R2 and it gives one output i.e., Vout.

If R1 and R2 values are equal, the output voltage will be half of the input voltage. If R2 is greater than R1, the output voltage will be near the input voltage. If R2 is lesser than R1, the output voltage will be very low because the drop across resistance will be less.

Applications

It can be used for level shifting
It can be used as a potentiometer
Used in labs for experiments
In resistive sensors

I hope you are comfortable with this voltage divider online calculator. Thank you for visiting.
