Single Capacitor Based Active Cell Balancing In MATLAB Simulink

Description

This price is for Indians, if you are from another country then your model price will be different it depends on your country’s currency- Chat with us on WhatsApp.



Hello guys, in this zip file you will find the Matlab Simulink model on a single capacitor-based active cell balancing.



The single switched capacitor (SSC) topology makes use of only one capacitor. The SSC needs a single capacitor and n + 5 bi-directional switches to balance n cells, making it more cost-efficient than SC and DTSC.

A relatively simple control strategy is always used, where the controller selects the high and low-energy cells and controls the corresponding switches for shuttling the energy between them. However, more advanced control strategies can be used for increasing the balancing speed, which will be discussed later in the proposed control strategy.

Generally, capacitor balancing is used to balance more than 4 cells because of its size and cost. For sure if the capacitor is used for balancing 4 cells or less (n ≠ 1) the SC will have fewer switches. But for more than 5 cells the SSC will have fewer switches than the SC system.
